| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CIF,EXW |
| Min. Order: | 30 Set/Sets |
| Transportation: | Ocean |
| Port: | Qingdao,Shanghai,Ningbo |
Main feature:
1.Attractive appearance, great ultraviolet ray Protection , sunfast.
2.Under Idle running, the rotation can below 600 rpm.
3.Low fuel consumption.
4.Noise free.
|
Model |
Unit |
80 |
80DI |
90 |
90DI |
|
Type |
|
Single Cylinder/Horizontal/Water Cooled/ 4-cycle |
|||
|
Bore x Stroke |
mm |
84x84 |
82x84 |
86x84 |
|
|
Displacement |
cc |
465 |
443 |
487 |
|
|
Maximum output |
Hp（kW）/rpm |
8（5.88）/2400 |
9（6.62）/2400 |
||
|
Continuous rated output |
Hp（kW）/rpm |
7（5.15）/2400 |
8（5.88）/2400 |
||
|
Fuel consumption |
g/Hp（kW）.h |
190（258） |
170（231） |
190（258） |
170（231） |
|
Rated speed |
rpm |
2400 |
|||
|
Idle speed |
rpm |
≤600 |
|||
|
Compression ratio |
|
23:01 |
18:01 |
22:01 |
18:01 |
|
Maximum torque |
kgf.m/rpm |
2.8/1600 |
2.9/1600 |
3.2/1600 |
|
|
Valve clearance（cold engine） |
mm |
0.160-0.200 |
|||
|
Cooling system |
|
Radiator |
|||
|
Governor system |
|
Flying hammer centrifugal speed type |
|||
|
Fuel Injection Pressure |
kgf/c㎡ |
120-125 |
190-210 |
120-125 |
190-210 |
|
Fuel delivery position |
|
19º-21º |
17º-19º |
19º-21º |
17º-19º |
|
Combustion system |
|
（TVCS）Three vortex combustion system |
Direct injection system |
（TVCS）Three vortex combustion system |
Direct injection system |
|
Lubricating system |
|
Forced Lubricating with Trochoid Pump |
|||
|
Lubricating oil |
|
API CF SAE 40（SAE 40 API CF） |
|||
|
Fuel |
|
（SAE No.2-D） |
|||
|
Fuel tank capacity |
L |
10 |
|||
|
Cooling water capacity |
L |
1.6 |
|||
|
Crankcase oil capacity |
L |
2.4 |
|||
|
Starting system |
|
Speed Doubling Handle by Hand/Electric Start |
|||
|
Direction of Rotation |
|
Counterclockwise Facing Flywheel |
|||
|
Lamp |
|
12V 35W/35W |
|||
|
Measurement |
mm |
769x342x482 |
|||
|
Net Weight |
kg |
83 |
89 |
||
| Selling Units | : | Set/Sets |
| Package Type | : | Wooden box packing |
