Main feature:
1.Attractive appearance, great ultraviolet ray Protection , sunfast.
2.Under Idle running, the rotation can below 600 rpm.
3.Low fuel consumption.
4.Noise free.
|
Model |
Unit |
95 |
100 |
110 |
120 |
|
Type |
|
Single Cylinder/Horizontal/Water Cooled/ 4-cycle |
|||
|
Bore x Stroke |
mm |
86x90 |
88x90 |
92x90 |
94x90 |
|
Displacement |
cc |
522 |
547 |
598 |
624 |
|
Maximum output |
Hp（kW）/rpm |
9.5（6.99）/2400 |
10（7.35）/2400 |
11（8.09）/2400 |
12（8.82）/2400 |
|
Continuous rated output |
Hp（kW）/rpm |
8.5（6.25）/2400 |
9（6.62）/2400 |
9.5（6.99）/2400 |
10.5（7.72）/2400 |
|
Fuel consumption |
g/Hp（kW）.h |
190（258） |
|||
|
Rated speed |
rpm |
2400 |
|||
|
Idle speed |
rpm |
≤600 |
|||
|
Compression ratio |
|
21.5：1 |
21:01 |
||
|
Valve clearance（cold engine） |
mm |
0.195-0.235 |
|||
|
Cooling system |
|
Radiator |
|||
|
Governor system |
|
Flying hammer centrifugal speed type |
|||
|
Fuel Injection Pressure |
kgf/c㎡ |
120-125 |
|||
|
Fuel delivery position |
|
19º-21º |
|||
|
Combustion system |
|
（TVCS）Three vortex combustion system |
|||
|
Lubricating system |
|
Forced Lubricating with Trochoid Pump |
|||
|
Lubricating oil |
|
SAE 40（SAE 40 API CF） |
|||
|
Fuel |
|
（SAE No.2-D） |
|||
|
Fuel tank capacity |
L |
11 |
|||
|
Cooling water capacity |
L |
2.1 |
|||
|
Crankcase oil capacity |
L |
2.8 |
|||
|
Starting system |
|
Speed Doubling Handle by Hand/Electric Start |
|||
|
Direction of Rotation |
|
Counterclockwise Facing Flywheel |
|||
|
Lamp |
|
12V 35W/35W |
|||
|
Measurement |
mm |
800x348x560 |
|||
|
Net Weight |
kg |
107 |
108 |
109 |
111 |
